Top Clear Roof Party Marquee Event Tent for Exhibition Trade Show Banquet
pecifications:
1,Easy to assemble and demount;
2.Waterproof, flame retardant,anti-UV radiation;
3.Hard pressed extruded aluminum&PVC cover and Solid Wall.
4.The tent is easy ro assemble and demount.
Fabric cover:
High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Our PVC fabric flame retardant according to German standard DIN4102 B1,M2 and USA standard CFM/NFPA 701.
Frame material:
Hard pressed extruded aluminum alloy, anodized surface handling, silver color, sturdy and never rust; over 15~20years life span.
Our aluminum alloy code 6061/T6,hardness achieved 15HW.The wind load capability is based on the aluminum hardness.
Steel components: Hot-dip galvanized steel, thickness is over 60um.
Covers : colourful cover, transparent cover, inflatable roof cover
Windows : dome or square clear PVC windows, mesh window, glass window for glass wall
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors : double wing glass door, single wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
Wall : soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
Fixing Methods: ground anchors, weight plate, expandable bolts
Rain Gutters : inner roof beam rain gutter or rain gutter between two similar tents
Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
| Specification | Width(m) | Bay distance(m) | Eave height(m) | Ridge height(m) | Main frame profile(mm) |
| MST-3 | 3 | 3 | 2.5 | 3 | 48x84x3 |
| MST-6 | 6 | 3 | 2.5 | 3.5 | 48x84x3 |
| MST-8 | 8 | 3 | 2.5 | 3.9 | 48x84x3 |
| MST-10 | 10 | 3 | 2.5 | 4.3 | 48x100x3 |
| MST-15 | 15 | 5 | 3 | 5.4 | 108x150x3 |
| MST-18 | 18 | 5 | 3 | 5.9 | 112x203x4 |
| MST-20 | 20 | 5 | 4 | 7.2 | 112x203x4 |
| MST-25 | 25 | 5 | 4 | 8 | 112x203x4 |
| MST-30 | 30 | 5 | 4 | 8.8 | 113x259x5 |
| MST-35 | 35 | 5 | 4 | 9.6 | 120x300x6 |
| MST-40 | 40 | 5 | 5 | 11.2 | 120x300x6 |
| The length can be extended by 3m bay such as 6m, 9m, 18m,,, by 5m bay such as 15m, 20m, 30m,,, Customized size or shape is available. | |||||
Services
1. Low MOQ is available.
2. Customized orders are available.
3. All colors and logo can be customized as customers' requirements.
4. Price is negotiable for large quantities order.
5. Follow up the order after you get, even offer engineer teams if you need.
6. We offer a one-year warranty for our sold products. Within the warranty period, we should offer free. on-site repair. At the same time, we shall offer paid service in case of the following circumstances:
A. Damage born of artificial behavior or irresistible natural phenomenon.
B. Breakdown or damage due to improper operation.
C. Breakdown or damage due to transformation, decomposition and assembly of products.
7. Upon receipt of repair notice, we will arrive at the site within 7 working days and solve the problem.
8. A user may consult related technical questions through after-sales telephone and receive a definite solution.
Functions
Using for birthday party, events party, catering, gathering, wedding events celebration and so on.
