500 People Large Canopy Party Wedding Outdoor Tent For Events and Exhibition
Canopy Tent Quick Details :
Place of Origin: Guangdong, China (Mainland)
Brand Name: T&C
Item Name: Wedding Tents
Frame: Hard pressed extruded aluminum alloy
Side Wall: PVC walls, glass wall, ABS wall, sandwich panel wall, etc.
Roof Cover: 850g/sqm double PVC-coated polyester textile
Plastic Type: Hot-DIP Galvanized
Ground Situation: Grassland, earth land, asphalt, cement ground, marble, etc.
Roof Fixing: Bar tensioning
Wind Resistance: 100 mph(44 meters per second)
Fixing Solution: Ground anchor, expandable bolt, weight plate, etc.
Service Life: More than 15 years
|
Tent Item NO |
Span Width (in Meter) |
Eave Height (in Meter) |
Ridge Height (in Meter) |
Unit Length for each module (in Meter) |
| GSL-3 | 3m | 2.5m | 3m | 3m |
| GSL-6 | 6m | 2.5m | 3.6m | 3m |
| GSL-8 | 8m | 2.5m | 4m | 3m |
| GSL-10 | 10m | 2.5m | 4.3m | 3m |
| GSL-15 | 15m | 3m | 5.4m | 5m |
| GSL-18 | 18m | 4m | 6.9m | 5m |
| GSL-21 | 21m | 4m | 7.4m | 5m |
| GSL-25 | 25m | 4m | 8m | 5m |
| GSL-30 | 30m | 4m | 8.8m | 5m |
| GSL-30 | 30m | 5m | 9.8m | 5m |
| GSL-40 | 40m | 5m | 11.5m | 5m |
| Length no limit, length module Qtys are designed as per client's request | ||||
Canopy Tent Frame Material:
1)High-strength aluminium alloy with PADF coating.
2)Conector is made of zinc powder-coated steel.
3)The frame is strong,durable,light in weight,not easy to rust and distort.
Canopy Tent Cover Material:
1)Double PVC-coated polyester textile.Any color is available.
2)Waterproof, flame retardant to DIN4102 B1, M2, UV resistant.
3)750g m2/850g/m2 PVC for roof cover,660g/m2 PVC for sidewall.
4)The maximum allowed wind speed is 100km/h.
T&C TENT Successful Cases:
· Kinds of New Style Tent for China Open
· Canton Fair Exhibition Hall
· 2011 Universiade Official Tent Supplier
· 2010 Asian Games Exclusive Tent Supplier&Sponsor
· Dior Event in Hong Kong
· China Grand Rally Sponsor
· Hong Kong Wine and Dine Festival
Other product
Company Information:
T&C Tent Co. LTD. Was established in 2005. Our company is the first professional manufacturer who introduced European advanced tents technology into our own design. Our main products include Modular Aluminium Alloy Structure Tents, Clear Span Tent Structure and Aluminium Alloy Square Pagoda & Summer Gazebo.
To form an integrated management system, TC Tent introduced advanced ERP system in 2008 and barcode management system in 2013. TC Tent is also the pioneer to apply CNC machines that achieved the automatic processing of aluminum.
